Wall mounted cleaning nozzles
使用阿法拉伐罐壁式清洗喷头可 100% 清洁储罐阴影区域。 此清洗喷嘴可安装在储罐的壁口或底部，通过与顶装式储罐清洗机配合使用，可清洁底部的搅拌器叶片、线圈和其他难以触及的区域。 它的可调清洗喷嘴具有经过优化的高冲击喷雾模式，可消除与储罐清洗不足相关的风险，确保更高的产品产量、更好的最终产品质量并降低运营成本。
更高效的储罐清洗可提高工艺效率和安全性，而且还可以提高产品质量和产量
- 100% 的储罐阴影区域清洗覆盖率可实现更快的批量和连续工艺转换，而且更安全且无污染
- 经过优化的高冲击喷雾模式可消除产品污染风险
- 即使在低压下也能高效、精确地清洗储罐，最多可减少 80% 的能源、水和清洁介质的使用
- 易于安装、操作和清洁
- 更快获得投资回报
阿法拉伐罐壁式清洗喷嘴
通过将阿法拉伐罐壁式清洗喷嘴与任何顶装式储罐清洗机配合使用，可消除储罐中的风险和污染，从而提高生产力、安全性和产量。 选择标准的介质驱动型号或 UltraPure 型号以及最适合您工艺的喷雾模式（无论储罐尺寸、设计或清洁任务如何）。 选项包括用于过程监控和反馈的气动模型和控制单元。 这种经济高效的储罐清洗喷嘴利用加压清洁介质来专门用于清洗阴影区域。 它非常适用于乳制品、食品、饮料、家庭个人护理、制药和其他行业，可降低能源、水和清洁介质成本，最大限度地减少对环境的影响并提供较低的总拥有成本。
罐壁式清洗喷嘴的工作原理?
Installed flush with the surface of the tank wall or bottom, a wall mounted tank cleaning nozzle contains a spring-activated piston, which opens and closes the nozzle depending on the pressure of the cleaning media. It is available in two versions: media driven or air-operated. During the Cleaning-in-Place process, the pressure created by the cleaning media activates the media-driven version, while the pneumatic air-operated version has an actuator, which automatically opens the nozzle by means of controlled air pressure. When activated, the wall mounted nozzle sprays a high impact fan of cleaning media directly toward the soiled area. Through controlled and repeated rotation of the equipment with shadow areas, such as agitator blades, the wall mounted tank cleaning nozzle hits the shadow areas, ensuring 100% cleaning coverage and high-precision, high-impact cleaning. Upon completion of the cleaning cycle, the integrated spring mechanism returns the piston to its original position, securely closing and sealing off the wall mounted cleaning nozzle. If purging is required, always operate with actuator.
Safeguard cheese production with 100% cleaning coverage of tank shadow areas
To increase cheese production by expanding its milk reception, a large Scandinavian dairy turned to the Beritech Group, an experienced tank and system builder. The objective was to guarantee complete cleaning coverage for two new 30-metre-high raw milk silos with bottom-mounted agitators.
